Salient Features
- + 1% Filling accuracy on single dose.
- Rigid vibration free construction for trouble free performance.
- S.S. elegantly matt finished body.
- .
- Elegant and easy control panel for total control on operation.
- Minium changeover time, from one size to another container or fill size.
- Automatic washing of conveyor belt (Optional).
- Reciprocating filling nozzle with self cantering device to avoid foaming.
- The unit is made compact & versatile – as per GMP norms
- No container no filling system – to avoid spillage.
- Synchrnoised A.C. drive for conveyor & main drive.
- Pneumatic control bottle stopper / Mechanical bottle control.
TECHNICAL SPECIFICATION
Model No. | SPFL-100A | SPFL-120A | SPFL-150A |
Output / Hour | 2500 to 6000 | 3500 to 9000 | 4500 to 12000 |
Electric Motor | Main Machine conveyor | 1HP / 440Volts / 3 Phase / 50(Four Wire) 0.5 HP / 440Volts / 3 Phase / 50(Four Wire) | |
Container Size | 30mm to 100mm, Maximum height 280mm | ||
Full Size | 10ml. To 500ml. (with the help of required change part) | ||
Overall Dimension | 1800(L) x 840(W) x 1400 (H) | 1850(L) x 1050(W) x 1400 (H) |
